Drag the security feature on the left to the specific security risks they help protect against on the
right. (Not all options are used.)
Answer
QUESTION 2
Routing has been configured on the local router with these commands:
Local(config)#ip route 0.0.0.0 0.0.0.0 192.168.1.1
Local(config)#ip route 10.1.0.0 255.255.255.0 192.168.2.2
Local(config)#ip route 10.1.0.0 255.255.0.0 192.168.3.3
Drag each destination IP address on the left to its correct next hop address on the right
Answer
QUESTION 3
The left describes the types of cables, while the right describes the purposes of the cables.
Drag the items on the left to the proper locations. (Not all items can be used.)
Answer
QUESTION 4
Drag each category on the left to its corresponding router output on the right. Each router output
line is in the result of a show ip interface command. (Not all categories are used.)
Answer
QUESTION 5
Drag the Cisco default administrative distance to the appropriate routing protocol or route (Not all
options are used.)
Answer
QUESTION 6
Drag the Frame Relay acronym on the left to match its definition on the right. (Not all acronyms
are used.)
Answer
QUESTION 7
A user is unable to connect to the Internet. Based on the layered approach to troubleshooting
and beginning with lowest layer, follow the guide and drag the contents to relevant modules
Answer
QUESTION 8
Drag and drop. Match the items on the left with its corresponding definition on the right.
Answer
QUESTION 9
Match the items on the left with appropriate OSI layer on the right. (Not all options are used.)
Answer
QUESTION 10
Refer to the exhibit. PC_1 is sending packets to the FTP server. Consider the packets as they
leave RouterA interface Fa0/0 towards RouterB. Drag the correct frame and packet address to
their place in the table.
Answer
QUESTION 11
Refer to the exhibit. FTP Server is sending packets to the PC_1. Consider the packets as they
leave RouterB interface Fa0/0 towards RouterA. Drag the correct frame and packet address to
their place in the table.
Answer
QUESTION 12
Refer to the exhibit. Complete the network diagram by dragging the correct device name or
description to the correct location. Not all the names or descriptions will be used.
Answer
Quiz-summary
0 of 12 questions completed
Questions:
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
Information
CCNA 200-120 Questions: Drag & Drop
You have already completed the quiz before. Hence you can not start it again.
Quiz is loading...
You must sign in or sign up to start the quiz.
You have to finish following quiz, to start this quiz:
Results
0 of 12 questions answered correctly
Your time:
Time has elapsed
You have reached 0 of 0 points, (0)
| Average score |
|
| Your score |
|
Categories
- Drag and Drop 0%
| Pos. | Name | Entered on | Points | Result |
|---|---|---|---|---|
| Table is loading | ||||
| No data available | ||||
- 1
- 2
- 3
- 4
- 5
- 6
- 7
- 8
- 9
- 10
- 11
- 12
- Answered
- Review
-
Question 1 of 12
1. Question
5 pointsDrag the security feature on the left to the specific security risks they help protect against on the right. (Not all options are used.)
Sort elements
- access to connected network or resources
- access to the console 0 line
- access to privileged mode
- remote access to device console
- viewing of passwords
-
access-group
-
console password
-
enable secret
-
VTY password
-
service password-encryption
Correct
Incorrect
-
Question 2 of 12
2. Question
6 pointsRouting has been configured on the local router with these commands:
Local(config)#ip route 0.0.0.0 0.0.0.0 192.168.1.1
Local(config)#ip route 10.1.0.0 255.255.255.0 192.168.2.2
Local(config)#ip route 10.1.0.0 255.255.0.0 192.168.3.3
Drag each destination IP address on the left to its correct next hop address on the rightSort elements
- Next hop 192.168.1.1 (A)
- Next hop 192.168.1.1 (B)
- Next hop 192.168.2.2 (C)
- Next hop 192.168.2.2 (D)
- Next hop 192.168.3.3 (E)
- Next hop 192.168.3.3 (F)
-
10.2.1.3 (A)
-
10.6.8.4 (B)
-
10.1.0.14 (C)
-
10.1.0.123 (D)
-
10.1.1.10 (E)
-
10.1.4.6 (F)
Correct
Incorrect
-
Question 3 of 12
3. Question
3 pointsThe left describes the types of cables, while the right describes the purposes of the cables.
Drag the items on the left to the proper locations. (Not all items can be used.)Sort elements
- switch access port to router
- switch to switch
- PC COM to Switch Console Port
-
straight-through
-
crossover
-
rollover
Correct
Incorrect
-
Question 4 of 12
4. Question
4 pointsDrag each category on the left to its corresponding router output on the right. Each router output line is in the result of a show ip interface command. (Not all categories are used.)
Sort elements
- Serial0/1 is up, line protocol is up
- Serial0/1 is up, line protocol is down
- Serial0/1 is down, line protocol is down
- Serial0/1 is administratively down, line protocol is down
-
Port operational
-
Layer 2 problem
-
Layer 1 problem
-
Port disabled
Correct
Incorrect
-
Question 5 of 12
5. Question
5 pointsDrag the Cisco default administrative distance to the appropriate routing protocol or route (Not all options are used.)
Sort elements
- RIP
- OSPF
- static route referencing IP address of next hop
- internal EIGRP route
- directly connected network
-
120
-
110
-
1
-
90
-
0
Correct
Incorrect
-
Question 6 of 12
6. Question
4 pointsDrag the Frame Relay acronym on the left to match its definition on the right. (Not all acronyms are used.)
Sort elements
- a router is this type of device
- the most common type of virtual circuit
- provides status message between DTE and DCE devices
- identifies the virtual connection between DTE and the switch
-
DTE
-
PVC
-
LMI
-
DLCI
Correct
Incorrect
-
Question 7 of 12
7. Question
4 pointsA user is unable to connect to the Internet. Based on the layered approach to troubleshooting and beginning with lowest layer, follow the guide and drag the contents to relevant modules
Sort elements
- verify Ethernet cable connection
- verify NIC operation
- verify IP configuration
- verify URL
-
Step 1
-
Step 2
-
Step 3
-
Step 4
Correct
Incorrect
-
Question 8 of 12
8. Question
6 pointsDrag and drop. Match the items on the left with its corresponding definition on the right.
Sort elements
- hop count
- bandwidth
- delay
- load
- reliability
- cost
-
the number of point-to-point links in a transmission path
-
the data capacity of a link
-
the amount of time required to move a packet from source to destination
-
the amount of activity on a network resource
-
usually refers to the bit error rate of each network link
-
a configurable value based by default on the bandwidth of the interface
Correct
Incorrect
-
Question 9 of 12
9. Question
6 pointsMatch the items on the left with appropriate OSI layer on the right. (Not all options are used.)
Sort elements
- packets (A)
- IP address (B)
- routing (C)
- udp (D)
- segments (E)
- windowing (F)
-
Network Layer (A)
-
Network Layer (B)
-
Network Layer (C)
-
Transport Layer (D)
-
Transport Layer (E)
-
Transport Layer (F)
Correct
Incorrect
-
Question 10 of 12
10. Question
4 points
Refer to the exhibit. PC_1 is sending packets to the FTP server. Consider the packets as they leave RouterA interface Fa0/0 towards RouterB. Drag the correct frame and packet address to their place in the table.
Sort elements
- MAC 0000:0c93:9999
- MAC 0000:0c87:3333
- IP 172.16.21.7
- IP 172.16.34.250
-
A
-
B
-
C
-
D
Correct
Incorrect
-
Question 11 of 12
11. Question
4 points
Refer to the exhibit. FTP Server is sending packets to the PC_1. Consider the packets as they leave RouterB interface Fa0/0 towards RouterA. Drag the correct frame and packet address to their place in the table.
Sort elements
- MAC 0000:0c87:3333
- MAC 0000:0c93:9999
- IP 172.16.34.250
- IP 172.16.21.7
-
A
-
B
-
C
-
D
Correct
Incorrect
-
Question 12 of 12
12. Question
6 points
Refer to the exhibit. Complete the network diagram by dragging the correct device name or description to the correct location. Not all the names or descriptions will be used.
Sort elements
- Router
- DTE
- DCE
- CSU / DSU Synchronous
- Digital Line
- WAN Service Provider Link
-
A
-
B
-
C
-
D
-
E
-
F
Correct
Incorrect
Blancko
What’s wrong with Q2 and Q9??
Alexey
Q 11 is wrong! “… packets as they leave RouterB interface Fa0/0 towards RouterA”. Because interface Fa0/0 of RouterB connect to SwitshB, not to RouterA!
